Description

Technical Specifications

Mechanical

Dimensions
358 x 271.95 x 272.5 mm (14.1 x 10.7 x 10.7″)

Weight
Without mount: 800 g (1.8 lb) With mount 980 g (2.2 lb)

Wind survivability
200 km/h (125 mph)

Wind loading
275 N at 200 km/h (61.8 lbf at 125 mph)

Hardware

Networking interface
(1) GbE RJ45 port

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply
24V, 0.3A gigabit PoE adapter (Included)

Supported voltage range
22–27V DC

Max. power consumption
7W

Max. power output
25 dBm

Gain
23 dBi

Ambient operating temperature
-40 to 70° C (-40 to 158° F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC

Operating Frequency (MHz)

Worldwide
5150-5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150-5250 MHz5250-5350 MHz5240-5725 MHz5725-5850 MHz

Management Radio (MHz)

Worldwide
2412 – 2472 MHz

US/CA
2412 – 2462 MHz
