Description

Technical Specifications

Mechanical

Dimensions 148 x 100 x 31 mm (5.8 x 3.9 x 1.2″)

Weight 432 g (15.2 oz)

Enclosure materialSGCC steel

Hardware

Management interface Ethernet In-Band

Networking interface(8) GbE RJ45 ports

PoE interface(4) PoE (Pins 1, 2+; 3, 6-)

Total non-blocking throughput 8 Gbps

Switching capacity 16 Gbps

Forwarding rate 11.9 Mpps

Power method (1) 48V DC, 2A Max.

Power supply External AC/DC adapter: 100-240V AC, 50/60 Hz; 48V DC, 1.25A

Supported voltage range44–57V DC

Max. power consumption12W (Excluding PoE output.)

Total available PoE48W

Max. PoE wattage per port by PSE15.4W

ESD/EMP protectionAir: ± 24kV, contact: ± 24kV

Ambient operating temperature-5 to 45° C (23 to 113° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

LEDs

EthernetPoELink/Speed/Activity
