Description

Technical Specifications

Mechanical

Dimensions
Ø160 x 31.45 mm (Ø6.3 x 1.2″)

Weight
Without mount: 170 g (6 oz)With mount: 185 g (6.5 oz)

Hardware

Networking interface(1) GbE RJ45 port

Management interfaceEthernet

Power method
PoEPassive PoE, 24V (Pairs 4, 5+; 7, 8 return)

Power supply
UniFi PoE switch
24V, 0.5A Gigabit PoE adapter**5-packs do not come with PoE adapters.

Max. power consumption
6.5W

Max. TX power2.4 GHz5 GHz6 GHz
20 dBm20 dBm –

MIMO2.4 GHz5 GHz6 GHz2 x 22 x 2 –

Throughput rate2.4 GHz5 GHz6 GHz300 Mbps867 Mbps –

Antenna gain2.4 GHz5 GHz6 GHz3 dBi3 dBi –

Button
Factory reset

Mounting
Wall, ceiling (Included)

Ambient operating temperature
-10 to 70° C (14 to 158° F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC

Software

WiFi standards
802.11 a/b/g/n/r/k/v/ac

Wireless security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)

BSSID
Up to 8 per radio

VLAN
802.1Q

Advanced QoS
Per-user rate limiting

Guest traffic isolation
Supported

Power save
Supported

WMM
Voice, video, best effort, and background

Concurrent clients
250+

Supported Data Rates (Mbps)

802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b
1, 2, 5.5, 11 Mbps

802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n
6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)

802.11ac
6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
