Description

Technical Specifications

Mechanical

DimensionsØ147 x 49 mm (Ø5.8 x 1.9″)

WeightWithout mount: 655 g (1.4 lb)With outdoor accessory: 685 g (1.5 lb)

Enclosure materialAluminum alloy, polycarbonate, hard-coated dome

Mount materialPolycarbonate, stainless steel

WeatherproofingIPX4

ResistanceIK08

Optics

Sensor5MP CMOS

LensFisheye lens

View angle360°

Night modeBuilt-in IR LED illumination and IR cut filter

Video

Resolution4MP 1920 x 1920 (1:1)

Max. frame rate30 FPS

Image settingsColor, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, masking, text overlay

System

ProcessorQuad-core Arm® Cortex®-A53 based chip

Networking interfaceGbE RJ45 port

Power methodPoE

Power supply48V DC, 0.18A PoE

Max. power consumption8.64W

Supported voltage range37—57V DC

LEDR/G/B/W

ButtonFactory reset

MountingSurface mount

Ambient operating temperature-20 to 40° C (-4 to 104° F)

Ambient operating humidity10 to 90% noncondensing

CertificationsFCC, IC, CE

Audio

MicrophoneYes (Can be disabled)

SpeakerYes

Software

Web applicationUniFi Protect: Version 1.10.0 and later

Mobile appUniFi Protect iOS™ and Android™
