Description

Technical Specifications

Mechanical

Dimensions
361 x 124.6 x 71.3 mm (14.2 x 4.9 x 2.8″)

Weight
752 g (1.66 lb)

Wind survivability
200 km/h (125 mph)

Wind loading
77 N at 200 km/h (17.3 lbf at 125 mph)

Hardware

Networking interface
(1) GbE RJ45 port

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply
24V, 0.3A gigabit PoE adapter (Included)

Supported voltage range
20—27V DC

Max. power consumption
7.1W

Max. TX power
25 dBm

Antenna gain
17 dBi

ESD/EMP protection
Air/contact ± 24kV

Shock and vibrations
ETSI300-019-1.4

Ambient operating temperature
-40 to 70° C (-40 to 158° F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC

Operating Frequency (MHz)

US/CAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150 – 5250 MHz5250 – 5350 MHz5470 – 5725 MHz5725 – 5850 MHz

Worldwide
5150 – 5875 MHz

Management Radio (MHz)

US/CA
2412 – 2462 MHz

Worldwide
2412 – 2472 MHz
