Description

Technical Specifications

Mechanical

Dimensions512 x 385.8 x 258.3 mm (20.2 x 15.2 x 10.2″)

WeightWithout mount: 1.4 kg (3 lb)With mount: 1.7 kg (3.8 lb)

Enclosure materialAluminum, plastic

MountingPole mount (Kit included)

Wind loading550 N at 200 km/h (123.6 lbf at 125 mph)

Wind survivability200 km/h (125 mph)

Hardware

Networking interface(1) GbE RJ45 port

Power methodPassive PoE 2-pair (4, 5+; 7, 8 return)

Power supply24V, 0.3A gigabit PoE adapter (Included)

Supported voltage range20-27V DC

Max. power consumption7W

Gain26 dBi

LEDsPower, Ethernet

ESD/EMP protection Air/contact ± 24kV

Channel sizesPtP mode: 10/20/30/40/50/60/80 MHzPtMP mode: 10/20/30/40 MHz

Ambient operating temperature-40 to 70° C (-40 to 158° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Operating Frequency (MHz)

Worldwide
5150-5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150-5250 MHz5250-5350 MHz5240-5725 MHz5725-5850 MHz

Management Radio (MHz)

Worldwide
2412 – 2472 MHz

US/CA
2412 – 2462 MHz
