Description

Technical Specifications

Mechanical

Dimensions
362 x 267 x 184 mm (14.25 x 10.5 x 7.2″)

Weight
750 g (1.7 lb)

Mounting
Pole mounting (Kit included)

Hardware

Networking interface
(1) 10/100 MbE RJ45 port

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply
24V, 0.2A PoE adapter (Included)

Supported voltage range
22–27V DC

Max. power consumption
7W

ESD/EMP protection
Air/contact ± 24kV

ETSI specification
EN 302 326 DN2

Shock and vibration
ETSI300-019-1.4

RoHS compliance
Yes

Ambient operating temperature
-40 to 70° C (-40 to 158° F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
FCC, IC, CE

Software

Operating frequency
Worldwide: 5150 – 5875 MHz
USA: 5725 – 5850 MHz

Output power
25 dBm

Gain
23 dBi

Max. VSWR
1.5:1
