Technical Specifications

Mechanical

Dimensions
189 x 189 x 125 mm (7.44 x 7.44 x 4.92″)

Weight
530 g (1.17 lb)

Enclosure material
UV-stabilized plastic

Mounting
Pole mount kit (Included)Wall mount (Not included)

Wind loading
45.4 N at 200 km/h (10.2 lbf at 125 mph)

Wind survivability
200 km/h (125 mph)

Hardware

Networking interface
(2) GbE RJ45 ports

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply
24V, 0.5A gigabit PoE adapter (Included)

Supported voltage range
20–27V DC

Max. power consumption
8.5W

ESD/EMP protection
Air/contact: ± 24kV

LEDs
Power, Ethernet, (4) Signal strength

Salt fog test
IEC 68-2-11 (ASTM B117)Equivalent: MIL-STD-810 G method 509.5

Vibration test
IEC 68-2-6

Temperature shock test
IEC 68-2-14

UV test
IEC 68-2-5 at 40° C (104° F)Equivalent: ETS 300 019-1-4

Wind-driven rain test
ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5

Ambient operating temperature
-40 to 80° C (-40 to 176 F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC

System

Gain
19 dBi

Channel sizes PtP ModePtPM Mode
10/20/30/40/50/60/80 MHz10/20/30/40 MHz

Max. VSWR
1.5:1

Polarization
Dual linear

Operating Frequency (MHz)

Worldwide
5150-5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150-5250 MHz5250-5350 MHz5240-5725 MHz5725-5850 MHz
