Technical Specifications

Mechanical

DimensionsWithout radome: 520 x 520 x 308 mm (20.5 x 20.5 x 12.1″)With radome: 525 x 525 x 315 mm (20.7 x 20.7 x 12.4″

WeightWithout radome: 2.35 kg (5.2 lb)With radome: 3.2 kg (7 lb)

Enclosure materialUV-stabilized plastic

MountingPole mount kit (Included)

Wind loading264.6 N at 96 km/h (60 lbf at 60 mph)

Wind survivability96 km/h (60 mph)

Hardware

Networking interface (1) GbE RJ45 port

Power method Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply24V, 0.5A gigabit PoE adapter (Included)

Supported voltage range 20-27V DC

Max. power consumption 8.5W

ESD/EMP protectionAir/contact: ± 24 kV

LEDs(1) Power, (1) LAN, (4) WLAN

Signal strength LEDsSoftware-adjustable to correspond to custom RSSI levels

Salt fog testIEC 68-2-11 (ASTM B117)Equivalent: MIL-STD-810 G method 509.5

Vibration testIEC 68-2-6

Temperature shock testIEC 68-2-14

UV testIEC 68-2-5 at 40° C (104° F)Equivalent: ETS 300 019-1-4

Wind-driven rain test ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5

Ambient operating temperature-40 to 70° C (-40 to 158° F)

Ambient operating humidity5 to 95% noncondensing

Certifications FCC, IC, CE, RoHS

System

Gain27 dBi

Max. VSWR 1.5:1

Channel sizesPtP ModePtMP Mode10/20/30/40/50/60/80 MHz10/20/30/40 MHz

PolarizationDual linear

Operating Frequency (MHz)

Worldwide 5150 – 5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-35150 – 5250 MHz5250 – 5350 MHz5470 – 5725 MHz5725 – 5850 MHz
