Technical Specifications

Mechanical

Dimensions
420 x 420 x 230 mm (16.5 x 16.5 x 9.1″)

Weight
2.2 kg (4.9 lb)

Enclosure material
UV-stabilized plastic, powder-coated SPCC

Wind loading
380 N at 200 km/h (85.4 lbf at 125 mph)

Wind survivability
200 km/h (125 mph)

Mounting
Pole mount kit (Included)

Hardware

Networking interface
(1) GbE RJ45 port

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Max. power consumption
8.5W

Supported voltage range
20—27V DC

Power supply
24V, 0.5A gigabit PoE adapter (Included)

ESD/EMP protection
Air/contact: ± 24 kV

LEDs
(1) Power, (1) LAN, (4) WLAN

Salt fog test
IEC 68-2-11 (ASTM B117)Equivalent: MIL-STD-810 G method 509.5

Vibration test
IEC 68-2-6

Temperature shock test
IEC 68-2-14

UV test
IEC 68-2-5 at 40° C (104° F)Equivalent: ETS 300 019-1-4

Wind-driven rain test
ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5

Ambient operating temperature
-40 to 70 C (-40 to 158 F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC, RoHS

System

Gain
25 dBi

Channel sizes
PtP Mode: 10/20/30/40/50/60/80 MHz
PtMP Mode: 10/20/30/40 MHz

Operating Frequency (MHz)

Worldwide
5150-5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150-5250 MHz5250-5350 MHz5240-5725 MHz5725-5850 MHz

Management Radio (MHz)

Worldwide
2412 – 2472 MHz

US/CA
2412 – 2462 MHz
