Description

Mechanical
Dimensions 420 x 420 x 289 mm (16.5 x 16.5 x 11.4″)
Weight 1.8 kg (4 lb)
Enclosure material UV-stabilized plastic
Mounting Pole mount kit (Included)
Wind loading 278.4 N @ 120 km/h (63 lbf @ 75 mph)
Wind survivability 120 km/h (75 mph)
Hardware
Networking interface (1) 10/100 MbE port
Power method Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply 24V, 0.5A PoE adapter (Included)
Supported voltage range 20–27V DC
Max. power consumption 6W
ESD/EMP protection Air/contact: ± 24 kV
LEDs (1) Power, (1) LAN, (4) WLAN
Signal strength LEDs Software-adjustable to correspond to custom RSSI levels
RoHS compliance Yes
Salt fog test IEC 68-2-11 (ASTM B117)
Equivalent: MIL-STD-810 G method 509.5
Vibration test IEC 68-2-6
Temperature shock test IEC 68-2-14
UV test IEC 68-2-5 at 40° C (104° F)
Equivalent: ETS 300 019-1-4
Wind-driven rain test ETS 300 019-1-4
Equivalent: MIL-STD-810 G method 506.5
Ambient operating temperature -40 to 70° C (-40 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications FCC, IC, CE
System
Gain 18 dBi
Operating frequency 2405-2475 MHz
Max. VSWR 1.5:1
Channel sizes 5/8/10/20/30/40 MHz
Polarization Dual linear
