Description

Technical Specifications

Mechanical

Dimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)

Weight3.9 kg (8.6 lb)

Enclosure materialAluminium CNC, SGCC steel

Mount materialSGCC steel

Hardware

ProcessorQuad-core ARM® Cortex®-A57 at 1.7 GHz

System memory4 GB DDR4

On-board storage16 GB eMMC

Management interfaceEthernet Bluetooth

Networking interfaceLAN: (8) GbE RJ45 ports(1) 10G SFP+ portWAN: (1) GbE RJ45 port(1) 10G SFP+ port

IDS/IPS throughput3.5 Gbps**Measured with iPerf3.

Power method(1) Universal AC input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input

Power supplyAC/DC, internal, 50W

Supported voltage range100—240V AC

Max. power consumption33W

ESD/EMP protectionAir: ± 15kV, contact: ± 8kV

LCM display(1) 1.3″ touchscreen

ButtonFactory reset

Ambient operating temperature-10° to 40° C (14° to 104° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Gateway Features

Performance Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting

Next-generation securityApplication-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced networkingLicense-free SD-WANWireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support

LEDs

EthernetLink/activityGreen: 1GAmber: 10/100M

SFP+Link/activityWhite: 10GGreen: 1G

HDDWhite: disk activityAmber: disk error

RPSBlue: ready
