Technical Specifications

Mechanical

Dimensions 204 x 43 x 235 mm (8 x 1.7 x 9.3″)

WeightWithout wall mount: 1.7 kg (3.8 lb) With wall mount: 1.8 kg (4 lb)

Hardware

Networking interface(8) 10/100/1000 Mbps RJ45 ports (2) 1 Gbps SFP ports

Management interface Ethernet In-Band, UART console Out-of-Band

PoE interface(8) PoE/PoE+ 2-pair (+1, 2; -3, 6) (8) 24V/0.7A 2-pair (+4, 5; -7, 8)

Total non-blocking line rate 10 Gbps

Max. power consumption 20W (Excludes PoE output)

Power method AC/DC integrated PSU, universal input
DC external, (Self-correcting polarity protection) terminal block input

Power supply Internal AC/DC 150W

Operating voltage100–240V AC, 50-60 Hz42–56V DC

LEDsSystemRJ45 Data PortsSFP Data Ports System: statusRJ45 ports: PoE; link/speed/activitySFP ports: link/speed/activity

ESD/EMP protection Air/contact: ± 24kV

Ambient operating temperatureInternal AC/DC at 150W: -25 to 45° C (-13 to 113° F)Internal AC/DC at 100W: -25 to 55° C (-13 to 131° F)External DC: -25 to 60° C (-13 to 140° F)

Ambient operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC
