Description

Technical Specifications

Mechanical

Dimensions442 x 325 x 44 mm (17.4 x 12.8 x 1.7″)

WeightWithout mounting brackets: 5.1 kg (11.3 lb)With mounting brackets: 5.2 kg (11.5 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(12) GbE RJ45 ports
(12) 2.5 GbE RJ45 ports(2) 10G SFP+ ports

PoE interface(24) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total non-blocking throughput62 Gbps

Switching capacity124 Gbps

Forwarding rate92.25 Mpps

Power method(1) Universal input, 100—240V AC, 8.5A Max., 50/60 Hz(1) USP-RPS DC input: 52V DC, 7.7A; 11.5V DC, 8.7A

Power supplyAC/DC, internal, 550W

Supported voltage range100—240V AC

Max. power consumption550W

Total available PoE400W

Max. PoE+ wattage per port by PSE34.2W

Voltage range PoE modePoE: 44— 57VPoE+: 50—57V

ServicesSMB Layer 3 PoE GbE switch

ESD/EMP protectionAir: ± 16kV, contact: ± 12kV

LCM display(1) 1.3″ color touchscreen

ButtonFactory reset

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity10 to 95% noncondensing

CertificationsCE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 featuresDHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs

LEDs

SystemStatus

EthernetLink/activity

SFP+Link/activity

Application Requirements

UniFi Network Version 5.14.12 and later
