Technical Specifications

Mechanical

Dimensions442 x 285 x 44 mm (17.4 x 11.2 x 1.7″)

WeightWithout mounting brackets: 4.5 kg (9.9 lb)With mounting brackets: 4.6 kg (11 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(24) 1/2.5/5/10 GbE ports(2) 25G SFP28 ports*
*Don’t support mixed speed at 25 Gbps mode. Once one of the ports is configured at 25 Gbps mode, the others will be limited at 25 Gbps too. Supports mixed speed when all ports are at 1 or 10 Gbps.

Total non-blocking throughput290 Gbps

Switching capacity580 Gbps

Forwarding rate431.52 Mpps

Power method(1) Universal input, 100—240V AC, 2A Max., 50/60 Hz(1) USP-RPS DC input, 11.5V DC, 8.7A

Power supplyAC/DC, internal, 100W

Supported voltage range100—240V AC

Max. power consumption100W

ServicesSMB Layer 3 GbE switch

ESD/EMP protectionAir: ± 16kV, contact: ± 12kV

LCM display(1) 1.3″ color touchscreen

ButtonFactory reset

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity10 to 95% noncondensing

CertificationsCE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 featuresDHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs

LEDs

SystemStatus

EthernetLink/activity

Application Requirements

UniFi Network Version 6.1.67 and later
