Description

Technical Specifications

Mechanical

DimensionsØ48.5 x 159.5 mm (Ø1.9 x 6.3″)

Weight315 g (0.7 lb)

Hardware

Networking interface(1) GbE RJ45 port

Management interfaceEthernet

Power methodPoE

Power supplyUniFi PoE switch48V, 0.32A Gigabit PoE adapter (Included)

Supported voltage range44—57V DC

Max. power consumption10.5W

Max. TX power2.4 GHz5 GHz23 dBm26 dBm

MIMO2.4 GHz5 GHz2 x 24 x 4

Throughput rate2.4 GHz5 GHz300Mbps1733 Mbps

Antenna gain2.4 GHz5 GHz1.6 dBi4 dBi

ButtonFactory reset

MountingWall, desktop, pole (Included)Ceiling (Optional)

Ambient operating temperature-30 to 70° C (-22 to 158° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Software

WiFi standards802.11 a/b/g/n/ac/ac-wave2

Wireless securityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3, TKIP/AES)

BSSID8 per radio

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Concurrent clients200+

Supported Data Rates

802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 -MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)
