Description

Technical Specifications

Mechanical

DimensionsWithout mount: Ø75.5 x 74.4 mm (Ø3 x 2.9″)
With mount: Ø75.5 x 150 mm (Ø3 x 5.9″)

WeightWithout mount: 225 g (8 oz)
With mount: 315 g (11.1 oz)

Enclosure materialPolycarbonate, aluminum alloy

Mount materialWall mount: aluminum alloy, polycarbonatePole mount: aluminum alloy

WeatherproofingIPX4

ResistanceIK04

Optics

Sensor5MP CMOS

LensFixed focal length

View angleH: 84.4°, V: 45.4°, D: 99.8°

Night modeBuilt-in IR LED illumination and IR cut filter

Video

Resolution4MP 2688 x 1512 (16:9)

Max. frame rate30 FPS

Image settingsColor, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking,
text overlay

System

ProcessorDual-core Arm® Cortex®-A7 based chip

Networking interface10/100 MbE RJ45 port

Max. power consumption4W

Power methodPoE

Supported voltage range37—57V DC

ButtonFactory reset

MountingWall, pole mount

Ambient operating temperature-20 to 40º C (-4 to 104º F)

Ambient operating humidity0 to 90% noncondensing

CertificationsFCC, IC, CE

Audio

MicrophoneYes (Can be disabled)

Software

Web applicationUniFi Protect: Version 2.2.7 or 2.7.28 and later

Mobile appUniFi Protect iOS™ and Android™: Version 1.10.0 and later
