Description

Technical Specifications

Mechanical

Dimensions192 x 185 x 44 mm (7.6 x 7.3 x 1.7″)

Weight1.2 kg (2.6 lb)

Enclosure materialPolycarbonate

Hardware

Management interfaceEthernet In-Band

Networking interface(16) GbE RJ45 ports

PoE interface(8) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total non-blocking throughput16 Gbps

Switching capacity32 Gbps

Power methodUniversal input, 100—240V AC

Power supplyAC/DC, internal, 60W

Max. power consumption15W (Excluding PoE output)

Total available PoE45W

Max. PoE wattage per port by PSE PoE+: 30W

ButtonFactory reset

Ambient operating temperature-15 to 40° C (5 to 104° F)

Ambient operating humidity10 to 90% noncondensing

CertificationsCE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 features–

LEDs

SystemStatus

EthernetPoESpeed/link/activity

PoELink/activity

Application Requirements

UniFi Network Version 7.2.94 and later
