Description

Technical Specifications

Mechanical

Dimensions 512.5 x 385.75 x 258.3 mm (20.2 x 15.2 x 10.2″)
Weight Without mount: 1.4 kg (3 lb) With mount: 1.7 kg (3.8 lb)
Enclosure materialUV-stabilized polycarbonate
Mounting Pole mount (Kit included)
Wind loading 550 N at 200 km/h (123.6 lbf at 125 mph)
Wind survivability 200 km/h (125 mph)

Hardware

Networking interface (1) GbE RJ45 port
Power method Passive PoE 2-pair (4, 5+; 7, 😎
Power supply 24V, 0.5A gigabit PoE adapter (Included)
Supported voltage range 22—27V DC
Max. power consumption 8.5W
ESD/EMP protection Air/contact: ± 24kV
Ambient operating temperature -40 to 60° C (-40 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC

Software

Modes
PtMP CPE, PtP**1.5.1 and later 1.5.x series firmware.

Services

SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog

Utilities
airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation

Auto distance adjustment
Yes

Auto power adjustment
Yes

Network
Bridge/Router* mode*Router mode is available in PtMP CPE mode only.

Security
Yes

Statical reporting
Yes

Management interface

Bluetooth management for easy setup over UISP AppWEB UI

Minimum software requirements

Any modern web browseriOS™ or Android™ based smartphone

System

Maximum throughput900+ Mbps**FW version 2.3.0 and later.

Encryption
WPA2-PSK (AES)

Uplink/downlink ratio
25/75, 33/67, 50/50

RF

Operating frequency*US/CA
U-NII-1
U-NII-2A
U-NII-2CU-NII-3
Worldwide5150 – 5250 MHz
5250 – 5350 MHz
5470 – 5725 MHz
5725 – 5850 MHz
4800 – 6200 MHz*Depends on regulatory region.

Management RadioWorldwide
2400 – 2483.5 MHz

Max. conducted TX power 22 dBm (per chain)
Channel bandwidth10/20/30/40/50/60/80/100 MHz**FW version 2.3.0 and later.
Antenna gain 26 dBi
