Description

Technical Specifications

Mechanical

Dimensions442 x 285 x 44 mm (17.4 x 11.2 x 1.7″)

WeightWithout mounting brackets: 4.3 kg (9.5 lb)
With mounting brackets: 4.4 kg (9.7 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(24) GbE RJ45 ports
(2) 1/10G SFP+ ports

PoE interface(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 😎

Total non-blocking throughput44 Gbps

Switching capacity88 Gbps

Forwarding rate65.472 Mpps

Power method(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP-RPS DC input, 52V DC, 7.69A; 11.5V DC, 2.61A

Power supplyAC/DC, internal, 450W

Supported voltage range100—240V AC

Max. power consumption50W (Excluding PoE output)

Total available PoE400W

Max. PoE wattage per port by PSE PoE+: 32W
PoE++: 64W

Voltage range PoE mode PoE: 44—57V
PoE+: 50—57V

ESD/EMP protectionAir: ± 16kV, contact: ± 12kV

LCM display (1) 1.3″ touchscreen

ButtonFactory reset

Shock and vibrationETSI300-019-1.4 Standard

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity10 to 90% noncondensing

CertificationsCE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 featuresDHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs

LEDs

SystemStatus

EthernetPoESpeed/link/activity

SFP+Link/activity

RPSStatus

Application Requirements

UniFi Network Version 5.10.5 and later
