Technical Specifications

Mechanical

Dimensions442 x 200 x 44 mm (17.4 x 7.9 x 1.7″)

WeightWithout mounting brackets: 3 kg (6.6 lb)
With mounting brackets: 3.1 kg (6.8 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(24) GbE RJ45 ports
(2) 1G SFP ports

PoE interface(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total non-blocking throughput26 Gbps

Switching capacity52 Gbps

Forwarding rate38.69 Mpps

Power methodUniversal input, 100—240V AC, 50/60 Hz

Power supplyAC/DC, internal, 120W

Supported voltage range100—240V AC

Max. power consumption25W (Excluding PoE output)

Total available PoE95W

Max. PoE wattage per port by PSE PoE+: 32W

Voltage range PoE mode PoE: 44—57V
PoE+: 50—57V

ESD/EMP protectionAir: ± 16kV, contact: ± 12kV

LCM display (1) 1.3″ touchscreen

ButtonFactory reset

Shock and vibrationETSI300-019-1.4 Standard

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity10 to 90% noncondensing

CertificationsCE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 features–

LEDs

SystemStatus

EthernetPoESpeed/link/activity

SFPLink/activity

Application Requirements

UniFi Network Version 7.2.94 and later
