Description

Technical Specifications

Mechanical

Dimensions139.7 x 96 x 31.2 mm (5.5 x 3.8 x 1.3″)

Weight460 g (1 lb)

Enclosure materialPlastic, aluminum

Mount materialAluminum

Hardware

Networking interface(1) Data-in: GbE RJ45 port(4) Data-out: GbE RJ45 ports

Management interfaceEthernetBluetooth

PoE interface(1) PoE in (PoE output not used)
(1) PoE out (Requires a PoE+ switch)

Power methodPoEPoE+ (Required for PoE output)

Power supplyUniFi PoE switch48V, 0.5A PoE adapter (Optional)

Max. power consumption13.5W (Excluding PoE output)

Max PoE wattage per port by PSE15.4W**Requires a PoE+ switch

Voltage range PoE mode44—57V DC

Max. TX power2.4 GHz5 GHz6 GHz22 dBm26 dBm –

MIMO2.4 GHz5 GHz6 GHz2 x 2 (UL MU-MIMO)4 x 4 (DL/UL MU-MIMO) –

Throughput rate2.4 GHz5 GHz6 GHz573.5 Mbps4.8 Gbps

Antenna gain2.4 GHz5 GHz6 GHz5 dBi5.9 dBi –

LEDWhite/blue

ButtonFactory reset

MountingWall (Included)

Ambient operating temperature-30 to 60° C (-22 to 140° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Software

WiFi standards802.11a/b/g/n/ac/ax

Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID8 per radio

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Concurrent clients300+

Zero-wait DFSYes**Supported with upcoming firmware versions.

Supported Data Rates

802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b1, 2, 5.5, 11 Mbps

802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)

802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network Version 6.4.52 and later
