Description

Technical Specifications

Mechanical

DimensionsØ48.5 x 159.5 mm (Ø1.9 x 6.3″)

Weight400 g (14.1 oz)

Enclosure materialPolycarbonate, aluminum

Mount materialPolycarbonate

WeatherproofingIPX5

Hardware

Networking interface(1) GbE RJ45 port

Management interfaceEthernetBluetooth

Power methodPoE

Power supplyUniFi PoE switch48V, 0.32A PoE adapter (Included)

Supported voltage range44—57V DC

Max. power consumption11.4W

Max. TX power2.4 GHz5 GHz6 GHz22 dBm26 dBm –

MIMO2.4 GHz5 GHz6 GHz2 x 2 (UL MU-MIMO)4 x 4 (DL/UL MU-MIMO) –

Throughput rate2.4 GHz5 GHz6 GHz573.5 Mbps4.8 Gbps –

Antenna gain2.4 GHz5 GHz6 GHz3 dBi5 dBi –

LEDsWhite/blue

ButtonFactory reset

MountingWall, desktop, pole (Included)Ceiling (Optional)

Ambient operating temperature-30 to 60° C (-22 to 140° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Software

WiFi standards802.11a/b/g/n/ac/ax

Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID8 per radio

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Concurrent clients300+

Zero wait DFS Yes**Supported with upcoming firmware versions

Supported Data Rates

802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b1, 2, 5.5, 11 Mbps

802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)

802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network Version 6.2.51 and later
