Description

Technical Specifications

Mechanical

DimensionsØ197 x 35 mm (Ø7.8 x 1.4″)

WeightWithout mount: 580 g (1.3 lb)
With mount: 720 g (1.6 lb)

Enclosure materialPolycarbonate

Mount materialStainless steel (SUS304)

WeatherproofingIP54

Hardware

Networking interface(1) GbE RJ45 port

Management interfaceEthernet
Bluetooth

Power methodPoE

Power supplyUniFi PoE switch
PoE adapter (Not included)

Supported voltage range44—57V DC

Max. power consumption13W

Max. TX power2.4 GHz5 GHz6 GHz22 dBm26 dBm –

MIMO2.4 GHz5 GHz6 GHz2 x 2 (UL MU-MIMO)4 x 4 (DL/UL MU-MIMO) –

Throughput rate2.4 GHz5 GHz6 GHz573.5 Mbps4.8 Gbps –

Antenna gain2.4 GHz5 GHz6 GHz4 dBi6 dBi –

LEDsWhite/blue

ButtonFactory reset

MountingWall, ceiling (Included)

Ambient operating temperature-30 to 60° C (-22 to 140° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Software

WiFi standards802.11a/b/g/n/ac/ax

Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID8 per radio

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Concurrent clients350+

Zero wait DFSYes**Supported with upcoming firmware versions

Supported Data Rates

802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b1, 2, 5.5, 11 Mbps

802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)

802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network Version 6.1.56 and later
