Description

Technical Specifications

Mechanical

Dimensions210.4 x 95 x 29 mm (8.3 x 3.7 x 1.1″)

Weight600 g (1.3 lb)

Enclosure materialPolycarbonate

Hardware

ProcessorDual-core 880 MHz, MIPS1004Kc

Memory512 MB DDR3

Onboard flash storage512 MB NAND

Networking interface(8) GbE RJ45 ports(1) 1G SFP port

Management interfaceEthernet In-BandBluetooth BLE

Power methodExternal AC/DC adapter

Power supply27V DC, 4.4A power adapter (included)

Supported voltage range24—28V DC

Max. power consumption10W (Excluding PoE output)

ESD/EMP protectionAir: ± 15kV, contact: ± 8kV

Ambient operating temperature-10 to 50° C (14 to 122° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

PoE

PoE interface(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 😎 or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 😎

Max. Passive PoE wattage per port30W/27V DC

Passive PoE voltage range27V DC

LEDs

SystemStatus

RJ45 data portsPoESpeed/link/activity

SFP data portLink/activity

Software

Management applicationUISP: Version 1.4.0 and later
