Description

Technical Specifications

Mechanical

Dimensions
224 x 82 x 48 mm (8.8 x 3.2 x 1.9″)

Weight
0.4 kg (0.8 lb)

Mounting
airFiber X mount (Rocket mount compatible)GPS Pole Mount (Included)

Weatherproofing
IP67**After installation of IP67 upgrade kit (included).

Hardware

Networking interface
(2) GbE RJ45 ports

Power method
Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 😎
Passive PoE 2-pairs (4, 5+; 7, 😎 or (1, 2+; 3, 6-)

Power supply
24V, 1A gigabit PoE adapter (Included)

Supported voltage range
18—54V DC

Max. power consumption
12W

GPS antenna
External, magnetic base

Ambient operating temperature
-40 to 55° C (-40 to 131° F)

Certifications
CE, FCC, IC

Software

Modes
PtP Master/Slave

Max. throughput
1+ Gbps

Max. range*
100+ km *Throughput and range values may vary depending on the environmental conditions.

Encryption
AES-256

RF

Max. TX power*
29 dBm*Depends on regional regulations.

Frequency accuracy
± 2.5 ppm without GPS Synchronization
± 0.2 ppm with GPS Synchronization

Channel bandwidth
10/20/30/40/50/60/80/100 MHz selectableProgrammable Uplink and Downlink duty cycles

Operating Frequency (MHz)

Worldwide4800 – 6200 MHz**Depends on regional regulations.

US/CAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150 – 5250 MHz5250 – 5350 MHz5470 – 5725 MHz5725 – 5850 MHz
