Description

Technical Specifications

Mechanical

Dimensions 235 x 43 x 204 mm (9.3 x 1.7 x 8″)

Weight 1.7 kg (3.7 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(8) GbE RJ45 ports
(2) 1G SFP ports

PoE interface(8) PoE/PoE+ (Pins 1, 2+; 3, 6-)24V DC passive PoE (Pins 4, 5+; 7, 😎

Total non-blocking throughput 10 Gbps

Switching capacity 20 Gbps

Forwarding rate 14.88 Mpps

Power method Universal input, 100—240V AC, 50/60 Hz

Power supply AC/DC, internal, 150W

Max. power consumption20W (Excluding PoE output)150W (Including PoE output)

Total available PoE130W

Max. PoE wattage per port by PSE PoE: 17W
PoE+: 34W

Voltage range PoE mode24V passive PoE: 20–27V
PoE+: 50—57V

ESD/EMP protectionAir: ± 24kV, contact: ± 24kV

Ambient operating temperature-5 to 45° C (23 to 113° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

LEDs

EthernetPoELink/Speed/Activity
