Description

Technical Specifications

Mechanical

Dimensions442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7″)

WeightWithout mounting brackets: 2.6 kg (5.8 lb)With mounting brackets: 2.7 kg (6 lb)

Enclosure materialSGCC steel

Hardware

Management interface Ethernet In-Band

Networking interface (8) 10G SFP+ ports

Total non-blocking throughput80 Gbps

Switching capacity 160 Gbps

Forwarding rate 119.04 Mpps

Power method Universal input, 100—240V AC, 50/60 Hz

Power supply AC/DC, internal, 36W

Supported voltage range100—240V AC

Max. power consumption 30W

ESD/EMP protection Air: ± 16kV, contact: ± 12kV

Max. number of supported SFP+ modules UACC-OM-MM-10G: 8UACC-OM-SM-10G: 8UACC-CM-RJ45-10G: 4 UACC-CM-RJ45-MG: 4

ServicesSMB Layer 2 GbE switch

LCM display(1) 1.3″ LCM color touchscreen

ButtonFactory reset

Ambient operating temperature -5 to 40° C (23 to 104° F)

Ambient operating humidity 10 to 90% noncondensing

Certifications CE, FCC, IC

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 features–

LEDs

SystemStatus

SFP+Link/activity

Application Requirements

UniFi Network Version 5.14.12 and later
