Description

Technical Specifications

Mechanical

DimensionsUVC-AI-Theta-Hub: 140 x 70 x 38 mm (5.5 x 2.8 x 1.5”) UVC-AI-Theta-Lens/360: Ø22.8. x 43.5 mm (Ø0.9 x 1.7”)

WeightUVC-AI-Theta-Hub: 330 g (11.6 oz) UVC-AI-Theta-Hub Mount: 35 g (1.2 oz) UVC-AI-Theta-Lens/360: 15 g (0.5 oz) UVC-AI-Theta-Lens/360 Flush Mount: 12 g (0.4 oz)

Enclosure material
UVC-AI-Theta-Hub: aluminum alloy UVC-AI-Theta-Lens/360: aluminum alloy, polycarbonate UVC-AI-Theta-Lens/360 Flush Mount: polycarbonate

Mount material
UVC-AI-Theta-Hub: aluminum alloy UVC-AI-Theta-Lens/360: aluminum alloy, polycarbonate UVC-AI-Theta-Lens/360 Flush Mount: polycarbonate

Cable jacket enclosure dimensions28 x 13 x 7.5 mm (1.1 x 0.5 x 0.3″)

Cable jacket enclosure materialPVC

Cable length1 m (3.3 ft)

Cable diameter3.7 mm (0.15″)

Cable jacket materialWoven fabric

Cable weight18 g (0.63 oz)

Cable connector typeTheta proprietary

Optics

SensorUVC-AI-Theta-Lens: 8MP CMOS UVC-AI-Theta-Lens-360: 12MP CMOS

LensFixed focal length

View angleUVC-AI-Theta-Lens: H: 97.5°, V: 79.4°, D: 118.2° UVC-AI-Theta-Lens-360: H: 180°, V: 180°, D: 180°

Video

ResolutionUVC-AI-Theta-Lens: 8MP 3264 x 2448 (4:3) UVC-AI-Theta-Lens-360: 6MP 2560 x 2560 (1:1)

Max. frame rateUVC-AI-Theta-Lens: 24 FPSUVC-AI-Theta-Lens-360: 20 FPS

Image settingsColor, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay

System

ProcessorQuad-core Arm® Cortex®-A53 based chip

Networking interfaceGbE RJ45 port

Max. power consumption12.5W

Power methodPoE

Power supply5V DC, 0.5A

Supported voltage range37—57V DC

Output power5V DC, 1A per port

LEDR/G/B/W

ButtonFactory reset

MountingWall, ceiling mount

Ambient operating temperature-20 to 40° C (-4 to 104o F)

Ambient operating humidity10 to 90% noncondensing

CertificationsFCC, IC, CE

Audio

MicrophoneSupports optional AI Theta Audio module for two-way audio (Sold separately)

SpeakerSupports optional AI Theta Audio module for two-way audio (Sold separately)

Software

Web applicationUniFi Protect: Version 2.7.18 and later

Mobile appUniFi Protect iOS™ and Android™: Version 1.11.0 and later
