Description

Technical Specifications

Mechanical

Dimensions 107 x 70 x 21 mm (4.2 x 2.8 x 0.8″)

Weight
150 g (5.3 oz)

Enclosure material
Polycarbonate

Hardware

Management interface
Ethernet In-Band

Networking interface
(5) GbE RJ45 ports

Total non-blocking throughput
5 Gbps

Switching capacity10 Gbps

Forwarding rate
7.44 Mpps

Power method
(1) USB Type C, 5V
(1) PoE/PoE+, 44—57V DC, 0.05—0.04A

Power supply
5V, 1A power adapter*
*Only single-unit packages include the 5V, 1A USB-C power adapter.

Supported voltage range
USB Type C: 4.7—5.3V DC
PoE/PoE+: 44—57V DC

Max. power consumption
2.5W

ESD/EMP protection
Air: ± 16kV, contact: ± 12kV

Button
Factory reset

Ambient operating temperature
-5 to 45° C (23 to 113° F)

Ambient operating humidity
10 to 90% noncondensing

Certifications
CE, FCC, IC

Switching Features

Layer 2 featuresPort isolation
Storm control
Port mirroring
Multicast / broadcast rate limiting
Flow control
Jumbo frames
Egress rate limit

Layer 3 features–

LEDs

System Status

Ethernet Speed/link/activity

Application Requirements

UniFi Network Version 5.12.5 and later
