Description

Technical Specifications

Mechanical

DimensionsØ109.2 x 64.5 mm (Ø4.3 x 2.5″)

WeightWithout mount: 370 g (13.1 oz) With mount: 390 g (13.8 oz)

Enclosure materialAluminum alloy, polycarbonate, hard-coated dome

Mount materialPolycarbonate, stainless steel

WeatherproofingIPX4

ResistanceIK08

Optics

Sensor5MP CMOS

LensFixed focal length

View angleH: 102.4°, V: 54.9°, D: 120.6°

Night modeBuilt-in IR LED illumination and IR cut filter

Video

Resolution4MP 2688 x 1512 (16:9)

Max. frame rate30 FPS

Image settingsColor, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking,
text overlay

System

ProcessorDual-core Arm® Cortex®-A7 based chip

Networking interface10/100 MbE RJ45 port

Max. power consumption5W

Power methodPoE

Supported voltage range37–57V DC

LEDR/G/B/W

ButtonFactory reset

MountingWall, ceiling mount

Ambient operating temperature-20 to 40º C (-4 to 104º F)

Ambient operating humidity0 to 90% noncondensing

CertificationsFCC, IC, CE

Audio

MicrophoneYes (Can be disabled)

SpeakerYes

Software

Web applicationUniFi Protect: Version 2.2.7 or 2.7.28 and later

Mobile appUniFi Protect iOS™ and Android™: Version 1.10.0 and later
