Technical Specifications

Mechanical

Dimensions316.5 x 316.5 x 174.3 mm (12.5 x 12.5 x 6.9″)

Weight1.3 kg (2.9 lb)

Enclosure material UV-stabilized polycarbonate

MountingPole mount (Kit included)

Wind loading150 N at 200 km/h (33.72 lbf at 125 mph)

Wind survivability200 km/h (125 mph)

Hardware

Networking interface(1) GbE RJ45 port

Power methodPassive PoE 2-pair (4, 5+; 7, 😎

Power supply24V, 0.5A gigabit PoE adapter (Included)

Supported voltage range22–27V DC

Max. power consumption9W

ESD/EMP protectionAir/contact: ± 24kV

Ambient operating temperature-40 to 60° C (-40 to 140° F)

Ambient operating humidity10 to 90% noncondensing

CertificationsCE, FCC, IC

Software

Modes
PtMP CPE, PtP**1.5.1 and later 1.5.x series firmware.

Services

SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog

Utilities
airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation

Auto distance adjustment
Yes

Auto power adjustment
Yes

Network
Bridge/Router* mode*Router mode is available in PtMP CPE mode only.

Security
Yes

Statical reporting
Yes

Management interface

Bluetooth management for easy setup over UISP AppWEB UI

Minimum software requirements

Any modern web browseriOS™ or Android™ based smartphone

System

Maximum throughput900+ Mbps**FW version 2.3.0 and later.

Encryption
WPA2-PSK (AES)

Uplink/downlink ratio
25/75, 33/67, 50/50

RF

Operating frequency*US/CA
U-NII-1
U-NII-2A
U-NII-2CU-NII-3
EU
Worldwide5150 – 5250 MHz
5250 – 5350 MHz
5470 – 5725 MHz
5725 – 5850 MHz
2400 – 2483.5 MHz
5150 – 5875 MHz
2400 – 2483.5 MHz
4800 – 6200 MHz*Depends on regulatory region.

Max. conducted TX power22 dBm (per chain)

Channel bandwidth10/20/30/40/50/60/80/100 MHz**FW version 2.3.0 and later.

Antenna gain24 dBi

Beamwidth14°

Sidelobe level-10 dB

Front-to-back ratio27 dB
