Description

Technical Specifications

Mechanical

Dimensions 442.4 x 325.6 x 43.7 mm (17.4 x 12.8 x 1.7″)
Weight
Without mount brackets : 5.5 kg (12.1 lb)
With mount brackets: 5.6 kg (12.3 lb)

Enclosure materialSGCC steel

Hardware

Networking interface(1) GbE RJ45 port

Management interfaceEthernet In-Band

Power output (6) RPS DC ports
Power method (1) Universal AC input, 100—240V AC
Max. power consumption 995W
Power supply Internal 350W AC/DC
Internal 645W AC/DC
Supported voltage range 100—240V AC
Total output power52V DC11.5V DC11.54A (600W)30.44A (350W)
Max. output power per RPS port52V DC11.5V DC11.54A (600W)30.44A (350W)
Display 1.3″ touchscreen
ESD/EMP protection Air: ± 16kV, contact: ± 12kV
Ambient operating temperature -5 to 45° C (23 to 113° F)
Ambient operating humidity 10 to 90% noncondensing
Certifications CE, FCC, IC

LEDs

SystemStatus

EthernetLink/activity

USP RPSActivity
