Description
Technical Specifications
Mechanical
DimensionsØ160 x 33 mm (Ø6.3 x 1.3″)
WeightWithout mount: 300 g (10.6 oz)With mount: 315 g (11.1 oz)
Enclosure materialPolycarbonate, aluminum
Mount materialPolycarbonate, SGCC steel
Hardware
Networking interface(1) GbE RJ45 port
Management interfaceEthernet
Bluetooth
Power methodPoEPassive PoE, 48V
Power supplyPoE
48V, 0.32A PoE adapter (Not included)
Supported voltage range44—57V DC
Max. power consumption12W
Max. TX power2.4 GHz5 GHz6 GHz23 dBm23 dBm –
MIMO2.4 GHz5 GHz6 GHz2 x 22 x 2 –
Throughput rate2.4 GHz5 GHz6 GHz300 Mbps1201 Mbps –
Antenna gain2.4 GHz5 GHz6 GHz2.8 dBi3 dBi –
LEDsWhite/blue
ButtonFactory reset
MountingWall, ceiling (Included)
Ambient operating temperature-30 to 60° C (-22 to 140° F)
Ambient operating humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Software
WiFi standards802.11a/b/g/n/ac/ax
Wireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID8 per radio
VLAN802.1Q
Advanced QoSPer-user rate limiting
Guest traffic isolationSupported
Concurrent clients300+
Supported Data Rates
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11ac (WiFi 5)6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
802.11ax (WiFi 6)7.3 Mbps to 1.2 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80)
Application Requirements
UniFi Network Version 5.14.3 and later
