Technical Specifications

Mechanical

Dimensions471.1 x 257.5 x 94.3 mm (18.6 x 10.1 x 3.7″)

Weight3.2 kg (7.1 lb)

WeatherproofingIP67

Hardware

Networking interface(1) GbE RJ45 port(1) 1/10 GbE ICM Ethernet port

Management interfaceEthernetBluetooth

Power methodPoE++

Power supplyGigabit PoE++ adapter 50V DC, 1.2A (Included)

Max. power consumption31W

Supported voltage range44—57V DC

Max. TX power2.4 GHz5 GHz6 GHz –25 dBm –

MIMO2.4 GHz5 GHz6 GHz –(3) 4 x 4 –

Throughput rate2.4 GHz5 GHz6 GHz –1.7 Gbps –

Antenna gain2.4 GHz5 GHz6 GHz –Small cell: 15 dBi / Large cell: 10 dBi –

AntennaIntegrated dual-mode antenna array

Operating frequency5 GHz low-band radio5 GHz mid-band radio5 GHz high-band radioCh 36-64Ch 100-132Ch 149-165

Antenna beamwidthSmall cellLarge cell50°90°

LEDsR/G/B

ButtonFactory reset

MountingVESA-compatible mount, pole/wall (Brackets included)

Ambient operating temperature-40 to 70° C (-40 to 158° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Software

WiFi standards802.11 a/n/r/k/v/ac/ac-wave2

Wireless securityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Power saveSupported

BeamformingSupported

WMMVoice, video, best effort, and background

Concurrent clients1500+

Supported Data Rates (Mbps)

802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11ac6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80)58 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 160)
