Description

Technical Specifications
Mechanical
Dimensions 196.5 x 93.5 x 39 mm ( 7.7 x 3.7 x 1.5″)
Weight 350 g (12.3 oz)
Enclosure material UV stabilized polycarbonate
Mounting material Stainless steel
Weatherproofing IPX5
Hardware
Networking interface (2) GbE RJ45 ports
PoE interface (1) Passthrough PoE output 2-pairs (pins 1,2+; 3,6-)
Power method PoE/PoE+ 2-pairs (pins 1, 2+; 3, 6-)*
*May not be supported by certain third-party switches. We recommend using a UniFi switch to power the device.
Max. power consumption (excluding PoE out) 1.5W
Voltage range 37—57V DC
ESD/EMP protection Air/contact: ± 30kV
DC sparkover voltage 90V at 100V/s
Max. impulse sparkover voltage 700V at 1kV/μs
Discharge current 10kA+
Max. MTU 1,500 bytes
Modes Long-range indoor
Outdoor ethernet repeater
Ambient operating temperature -40 to 80° C (-40 to 176° F)
Ambient operating humidity 10 to 95% non-condensing
Certifications CE, FCC, IC
LEDs
System Blue: power ON
Ethernet Green: 1 Gbps
Amber: 10/100 Mbps
PoE Amber: passthrough PoE out
