Technical Specifications

Mechanical

DimensionsWithout mount: 257 x 84 x 41 mm (10.1 x 3.3 x 1.6″)With mount: 257 x 84 x 30 mm (10.1 x 3.3 x 1.2″)

Weight233 g (8.2 oz)

Enclosure material
UV-resistant plastic

MountingPole and wall mounting kits (Included)

Hardware

Networking interface(2) GbE RJ45 ports

Power methodPoE alternative A (pairs 1, 2+; 3, 6 Return)
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply24V, 0.5A gigabit PoE adapter (Included)

Supported voltage range44–54V DC
22–27V DC

Max. power consumption9W

ESD/EMP protectionAir/contact: ±24 kV

LEDsPower, Ethernet, (4) signal strength

Ambient operating temperature-40 to 70° C (-40 to 158° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

System

Gain16 dBi

Channel bandwidths10/20/30/40/50/60/80 MHz

Cross-pol isolation20 dB min.

Max. VSWR1.6:1

Beamwidth45° (H-pol) / 45° (V-pol) / 45° (Elevation)

PolarizationDual linear

Operating Frequency (MHz)

Worldwide
5150-5875 MHz

USAU-NII-1U-NII-2AU-NII-2CU-NII-3
5150-5250 MHz5250-5350 MHz5240-5725 MHz5725-5850 MHz

Management Radio (MHz)

Worldwide
2412 – 2472 MHz

US/CA
2412 – 2462 MHz
