Technical Specifications

Mechanical

Dimensions442 x 325 x 87 mm (17.4 x 12.8 x 3.4″)

WeightWithout mounting brackets: 9.2 kg (20.3 lb)With mounting brackets: 9.5 kg (20.8 lb)

Enclosure materialSGCC steel

Mount materialSGCC steel

Hardware

Management interfaceEthernet In-Band

Networking interface(1) GbE RJ45 port(1) 1/10 GbE SFP+ port

RF interfaceBluetooth 4.1

Power method(1) Universal AC input, 100—240V AC, 3A Max., 50/60 Hz(1) USP-RPS DC input, 11.5V DC, 13.91A

Power supplyAC/DC, internal, 200W

Supported voltage range100—240V AC

Max. power consumption160W

Max. power budget for Drives135W

ESD/EMP protectionAir: ± 12kV, contact: ± 8kV

LCM display(1) 1.3″ touchscreen

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsFCC, CE, IC

LEDs

System(1) Power: blue/whiteFlashing white: bootup in progressFlashing blue: firmware upgradingSteady white: factory defaults, awaiting adoptionSteady blue: device is adopted

EthernetGreen: 1 GbpsAmber: 10/100 Mbps

SFP+White: 10 GbpsGreen: 1 Gbps

HDDWhite: disk detectedAmber: disk error

RPSBlue: ready
