Description

Technical Specifications

Mechanical

Dimensions485 x 374.6 x 43.7 mm (19.1 x 14.8 x 1.7″)

Weight6.1 kg (13.5 lb)

Enclosure materialSGCC steel

Hardware

Management interfaceEthernet In-Band(1) RJ45 Serial port Out-of-Band

Networking interface(48) GbE RJ45 ports
(2) 1G SFP ports
(2) 1/10G SFP+ ports

PoE interface(48) PoE/PoE+ (Pins 1, 2+; 3, 6-)
24V DC passive PoE (Pins 4, 5+; 7, 😎

Total non-blocking throughput70 Gbps

Switching capacity140 Gbps

Forwarding rate104.16 Mpps

Power methodUniversal input, 100—240V AC, 50/60 Hz

Power supplyAC/DC, internal, 500W

Supported voltage range100—240V AC

Max. power consumptionExcluding PoE output: 64WIncluding PoE output: 500W

Total available PoE500W

Max. PoE wattage per port by PSE 24V Passive PoE: 17WPoE+: 34W

Voltage range PoE mode 24V Passive PoE: 20–27VPoE+: 50—57V

ESD/EMP protectionAir: ± 24kV, contact: ± 24kV

Sound level*
Fan level 0
Fan level 1
Fan level 2
Fan level 310.7 dBr
16.2 dBr
19.3 dBr
23.6 dBr
* Background noise level: 27.5 dBa.

Shock and vibrationETSI300-019-1.4 Standard

Ambient operating temperature-5 to 40° C (23 to 104° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

LEDs

SystemStatus

EthernetPoESpeed/Link/Activity

SFPSpeed/Link/Activity
