Technical Specifications

Mechanical

Dimensions
88 x 40 x 230 mm (3.5 x 1.6 x 9.1″)

Weight
400 g (14.1 oz)

Enclosure material
Die-cast aluminum

Mounting
Pole mounting (Kit included)

Wind loading
342.5 N at 200 km/h (77 lbf at 125 mph)

Hardware

Networking interface
(1) GbE RJ45 port

RF connectors
(2) RP-SMA (Waterproof)(1) GPS (Waterproof)

Power method
Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply
24V, 1A gigabit PoE adapter (Included)

Supported voltage range
18—27V DC

Max. power consumption
9.5W

LEDs
(4) Signal strength: software-adjustable to correspond to custom RSSI levels GPS, LAN, power

Shock and vibrations
ETSI300-019-1.4

Ambient operating temperature
-40 to 80° C (-40 to 176° F)

Ambient operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC, RoHS

Software

Modes
Access Point, station

Channel sizesPtP modePtMP mode
10/20/30/40/50/60/80 MHz10/20/30/40 MHz

Services
Web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing

Utilities
airMagic, airView, antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test

Distance adjustment
Dynamic Ack and Ackless mode

Power adjustment
Software adjustable UI or CLI

Security
WPA2 AES only

QoS
Supports packet level classification WMM and user customer level: High/Medium/Low

Statistical reporting
Up time, packet errors, data rates, wireless distance, Ethernet link rate

Ubiquiti specific features
30/50/60 MHz Channels, airMAX ac mode, traffic shaping with burst support, discovery protocol, frequency band offset, Ackless mode

Operating Frequency (MHz)

Worldwide
5150–5875 MHz

USAU-NII-1: U-NII-2A: U-NII-2C: U-NII-3
5150–5250 MHz5250–5350 MHz5470–5725 MHz5725–5850 MHz

Management Radio (MHz)

Worldwide
2412–2472 MHz

USA
2412–2462 MHz
