Description

Technical Specifications

Mechanical

DimensionsØ110 x 184.1 mm (Ø4.3 x 7.3″)

Weight1.2 kg (2.5 lb)

Enclosure materialPolycarbonate

Hardware

ProcessorDual-core Arm® Cortex® A53 at 1.35 GHz

System memory2 GB

Expansion slotMicro SD memory card**Requires a memory card with at least 128 GB of storage.

Management interfaceEthernetBluetooth

Networking interfaceLAN: (4) GbE RJ45 portsWAN: (1) GbE RJ45 port

PoE interface(2) PoE (Pair B 4, 5+; 7, 😎

Power methodUniversal AC input, 100—240V AC, 1.1A Max., 50/60 Hz

Power supplyAC/DC, internal, 50W

Supported voltage range100—240V DC

Max. power consumption19.37W (Excluding PoE output)

PoE budget40W

Max. PoE wattage per port by PSE15.4W

Voltage range PoE mode44—57V DC

Max. TX power2.4 GHz5 GHz26 dBm26 dBm

MIMO2.4 GHz5 GHz4 x 44 x 4

Throughput rate2.4 GHz5 GHz600 Mbps2.4 Gbps

Antenna gain2.4 GHz5 GHz3.4 dBi4.3 dBi

Antenna(1) Internal, dual-band, quad-polarity antenna

LCM display(1) 0.96″ screen

ButtonFactory reset

LEDsWhite/blue

Ambient operating temperature-10 to 45° C (14 to 113° F)

Ambient operating humidity5 to 95% noncondensing

CertificationsCE, FCC, IC

Gateway Features

Performance
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting

Next-generation securityApplication-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall

Advanced networkingLicense-free SD-WANWireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support

Software

WiFi standards802.11a/b/g/n/ac/ax

Wireless securityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID8 per radio

VLAN802.1Q

Advanced QoSPer-user rate limiting

Guest traffic isolationSupported

Concurrent clients300+

Supported Data Rates

802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b1, 2, 5.5, 11 Mbps

802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)

802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
